Cinder block stand

jaws7777

Probation Member
Probation Member
Mar 1, 2014
17,773
20,945
740
White house 1600 Pennsylvania Ave NW, Washington
Guys im looking for quick and cheap way to build a stand for a 75 gal or 40b tank.

Can you guys give me some pointers on doing it with cinderblocks and possibly post some pics of you're stands.

Some questions off the top of my head:

Points of contact - where on the bottom of the tank should it contact with the blocks ?

Leveling- if the floor is off is it advisable to level just blocks that are off ? Also i would assume i'd have to level or shim all the way around any given block tht requires leveling ?

Should i put ply wood between the tank and blocks ?

Do these type of stands hold up over time ?


tlindsey

Silver Tier VIP
MFK Member
Aug 6, 2011
23,759
24,787
1,660
Ohio
Never used Cinder blocks but wanted to for my 180 gallon, so instead built the stand out of wood. If you 4 corner the 75 gallon you should be fine. Shim if necessary while aquarium is empty with a contractor level.

  • Like
Reactions: jaws7777

monkeybike

Aimara
MFK Member
Mar 13, 2015
1,211
857
125
At the store, we used chimney blocks on end with a 2x4 frame the size of the tank frame sitting on top.


jaws7777

Probation Member
Probation Member
Mar 1, 2014
17,773
20,945
740
White house 1600 Pennsylvania Ave NW, Washington
Thx guys do i need points of contact towards the middle if the tank ?

  • Like
Reactions: tlindsey

jaws7777

Probation Member
Probation Member
Mar 1, 2014
17,773
20,945
740
White house 1600 Pennsylvania Ave NW, Washington
  • Like
Reactions: tlindsey

flukekiller

Piranha
MFK Member
Aug 2, 2014
698
375
77
45
gloucester, va 23061
thanks, i did away with it though cause it got dirty real fast and was a pain to clean


Drstrangelove

Potamotrygon
MFK Member
Oct 21, 2012
2,693
1,227
164
San Francisco
I've used several cinder block stands.

1) Do not put the tank directly on the blocks. Use plywood or 2x4's to go underneath the tank.

2) It's okay with a glass tank to have nothing under the spans, but heck, blocks are cheap and so are 2x4's. I used 4 2x4's (placed tall side flat) to span two columns of cinder blocks. For stability, I placed a thin plywood on top that I glued to the 2x4s.

3) do not stack cinder blocks more than 3 high.

The blocks are strongest for supporting loads with the hollow spaces vertical. Not horizontal.

I'm not saying they will collapse under a 75 the other way; just saying your risk of collapse is lower if you point them in the strongest direction. They are pretty strong either way.

Last edited:

jaws7777

Probation Member
Probation Member
Mar 1, 2014
17,773
20,945
740
White house 1600 Pennsylvania Ave NW, Washington
I've used several cinder block stands.

1) Do not put the tank directly on the blocks. Use plywood or 2x4's to go underneath the tank.

2) It's okay with a glass tank to have nothing under the spans, but heck, blocks are cheap and so are 2x4's. I used 4 2x4's (placed tall side flat) to span two columns of cinder blocks. For stability, I placed a thin plywood on top that I glued to the 2x4s.

3) do not stack cinder blocks more than 3 high.

The blocks are strongest for supporting loads with the hollow spaces vertical. Not horizontal.

I'm not saying they will collapse under a 75 the other way; just saying your risk of collapse is lower if you point them in the strongest direction. They are pretty strong either way.
Great tip with pointing the blocks vertical thank you
