Glass for plywood aquarium

Daddypurcell86

Feeder Fish
Original poster
Sep 29, 2019
1
0
1
33
I’m looking to build a single pane plywood aquarium dimensions are going to be 84” x 30” x 30”. The glass I’m thinking 72” x 24” but I’m not sure what thickness I need. Not sure if I should go with 1/2” or 3/4”? I want to make sure it’s not going to flex and break because it’s going on my living room with he’s wood floor. Also has anyone ever built a plywood tank with acrylic viewing panel, can’t find anything definitive on that or how to do it since acrylic doesn’t like wood.


sikoko

Polypterus
MFK Member
Aug 15, 2009
1,409
198
96
28
Groton,ct
I believe acrylic is used for smaller viewing windows, if you're worried about glass thickness go with what you feel comfortable with 3/4" is recommended . And always test fill for a bit to ensure no leaks or seepage. You should also post a build thread but beware mfkers are like piranha when it comes to updates usually.


Canoeist

Exodon
MFK Member
Sep 12, 2019
86
54
21
37
I typed "plywood glass" into the search and there are a few decent threads. Customaquarium.com has a glass calculator.

  • Like
Reactions: BIG-G

TexasMFK31

Dovii
MFK Member
Jun 1, 2017
577
659
105
31

It's a sticky post.


wannadivesteve

Jack Dempsey
MFK Member
Sep 10, 2015
165
59
36
61
Oregon
I think member Stempy built a large aquarium with an acrylic window that seemed to be sucessful. He used a sealant (Dow 795 if I recall) that boat builders use on hatches a lot because it'll bond both fiberglass and plastic. Might want to search for his posts. I think several others have used it to attach glass to pond liner. It isn't that acrylic doesn't like wood, it's that most silicone sealants work poorly on acrylic.

  • Like
Reactions: BichirKing

twentyleagues

Blue Tier VIP
MFK Member
Apr 5, 2017
4,674
6,485
429
Flint town!
Most glass calculators say 1/2 up to 30" 5/8 or 3/4 over 30" up to 40" I think. If you can find 5/8 may be the extra safety factor you want.
