Oh so there is a central brace at the middle of the tank. I'm guessing that if this were removed, as I would like, then I'd have to do the 12mm? Thanks for your time and patience too! It is being most appreciated.

Saintnova said:
Oh so there is a central brace at the middle of the tank. I'm guessing that if this were removed, as I would like, then I'd have to do the 12mm? Thanks for your time and patience too! It is being most appreciated.
Click to expand...

Yes there is one cross brace. Ive got some smaller tanks that only have the brace along front and back.

Tobiassorensen said:
Yes there is one cross brace. Ive got some smaller tanks that only have the brace along front and back.
Click to expand...


Ok so let me finalize in my head. A 137cm x 55 x 60 tank will be good with 12mm glass and only top Eurobracing and no center brace? Any idea of a safety factor? I can calculate without the Eurobrace but I don't know how much the brace adds.

Saintnova said:
Ok so let me finalize in my head. A 137cm x 55 x 60 tank will be good with 12mm glass and only top Eurobracing and no center brace? Any idea of a safety factor? I can calculate without the Eurobrace but I don't know how much the brace adds.
Click to expand...

Yes just bracing along front and back adds alot but i would not go without the crossbrace at all IMHO. One centerbrace adds alot to the safetyfactor. And it is quite practical when putting glasslids and lets say an led.

  • Like
Reactions: TexasMFK31
Tobiassorensen said:
Yes just bracing along front and back adds alot but i would not go without the crossbrace at all IMHO. One centerbrace adds alot to the safetyfactor. And it is quite practical when putting glasslids and lets say an led.
Click to expand...


Aargh! The not wanting a center brace was the whole point of thickening the glass and doing Eurobracing. My current reef tank has a center brace and it blocks so much light that no matter how clean it is, it casts a noticeable shadow. The tank will be only 22 high. Aargh!

Saintnova said:
Aargh! The not wanting a center brace was the whole point of thickening the glass and doing Eurobracing. My current reef tank has a center brace and it blocks so much light that no matter how clean it is, it casts a noticeable shadow. The tank will be only 22 high. Aargh!
Click to expand...

You can do it without but its your call. I think my 120x45x50cm tanks are built out of 8mm glass and only having brace front and backpanels. No centerbrace.


Oh ok. Sounds like we aren't too far off then are we. Thanks for the help. Gonna cut the main pieces and wait a day or two more to see if we get some added confirmation. You guys know big tanks. Just want that added confirmation that someone has done it and it's safe. Oh, by the way. Side pieces on top of the bottom glass or at the sides?

Saintnova said:
Oh ok. Sounds like we aren't too far off then are we. Thanks for the help. Gonna cut the main pieces and wait a day or two more to see if we get some added confirmation. You guys know big tanks. Just want that added confirmation that someone has done it and it's safe. Oh, by the way. Side pieces on top of the bottom glass or at the sides?
Click to expand...

I always build at the sides of the bottompanel.

Noted. Mine is built like that but have seen it the other way but without explanation.
